Tip

All input files can be downloaded: Files.

Tip

For more information of this section, please refer to these pages:

Semi-empirical Quantum Chemistry Methods

This tutorial will lead you step by step to do semi-empirical quantum chemistry calculations using Qbics. There are two semi-empirical methods implemented in Qbics: xTB and NDDO (neglect of diatomic differential overlap). While xTB is a modern one with better accuracy and speed, NDDO is a traditional semi-empirical method, which is still widely used in many fields. Note that NDDO is a series of methods, including AM1, PM3, PM6, etc, which are all available in Qbics.

xTB can be applied for elements from H to Rn (Z=86), while NDDO is only for elements from H to Cl (Z=17). xTB is more accurate than NDDO in general, but NDDO has some special parameterizations for specific systems, such as biomolecules. You can choose either one according to your needs.

Example: xTB for Ligand-protecing Gold Clusters

We will use xTB to calculate the binding energy of a ligand-protecting gold cluster, Au18(C6H11S)14, which is a model for gold nanoparticles:

../_images/a14.jpg

The input file is:

aulig.inp
  1mol
  2   Au    6.95958    2.87913    2.94614
  3    S    9.08599    3.67339    2.88510
  4    S    4.89113    1.81941    3.01855
  5   Au    5.82923    4.53162    5.05796
  6   Au    4.13669    3.38239    1.49897
  7   Au    5.79250    5.99300    2.82997
  8   Au    8.65595    5.47861    4.26420
  9    S    3.33616    4.66634   -0.18204
 10   Au    3.45811    5.08053    3.76279
 11    S    8.56081    7.20090    5.75077
 12   Au    6.24304    7.42405    5.38760
 13    S    7.04744    3.53845    6.81588
 14   Au    3.89147    6.19365    6.32206
 15   Au    6.56834    5.22532    8.23897
 16    S    6.65568    7.45648    1.19187
 17   Au    3.92517    7.94284    4.15361
 18   Au    3.18725    6.66426    1.06638
 19   Au    6.51959    9.17260    2.68377
 20    S    1.11550    4.78967    4.09094
 21   Au    0.97656    6.80219    5.13736
 22    S    3.01320    8.66765    2.07979
 23    S    6.26671    7.02193    9.67527
 24   Au    5.18561    8.18601    7.95848
 25   Au    5.18171    9.94301    5.85487
 26    S    3.00776    5.17778    8.25337
 27   Au    2.88045    8.79374    6.73399
 28    S    0.61480    8.81770    6.18653
 29    S    6.59196   10.92950    4.17781
 30   Au    3.60146   10.47321    8.93384
 31   Au    2.73505    7.19691    9.38807
 32    S    3.42541    8.93876   10.69319
 33    S    4.56391   11.83306    7.37982
 34    C    4.95046    0.19661    2.19906
 35    C    4.13304    0.27617    0.92539
 36    C    6.43827   -0.19882    1.91962
 37    H    4.54937   -0.47352    2.79236
 38    C    4.32830   -1.08837    0.26931
 39    H    4.45695    0.98625    0.34829
 40    H    3.19681    0.43452    1.12181
 41    C    5.75611   -1.40758   -0.15592
 42    H    4.03232   -1.77426    0.88894
 43    H    3.75560   -1.14070   -0.51433
 44    C    6.56085   -1.57337    1.12181
 45    H    5.78086   -2.22375   -0.68037
 46    H    6.11951   -0.68416   -0.69252
 47    H    7.48911   -1.76356    0.91526
 48    H    6.20590   -2.30489    1.65233
 49    H    6.91097   -0.27514    2.76401
 50    H    6.86172    0.50545    1.40529
 51    C    9.82213    2.61150    4.17741
 52    C   11.27211    3.02202    4.31713
 53    C    9.74817    1.08389    3.77445
 54    H    9.35450    2.75237    5.02585
 55    C   10.56493    0.41654    4.92663
 56    H    8.83144    0.76495    3.75825
 57    H   10.15792    0.92343    2.90981
 58    C   12.02599    0.81419    4.94688
 59    H   10.16185    0.65719    5.77507
 60    H   10.50409   -0.54817    4.83551
 61    C   12.15597    2.23072    5.30934
 62    H   12.50229    0.26663    5.59080
 63    H   12.41786    0.66328    4.07414
 64    H   13.08043    2.51488    5.23847
 65    H   11.85571    2.37597    6.22055
 66    H   11.29164    3.95583    4.58037
 67    H   11.68263    2.96345    3.44034
 68    C    4.66625    4.65474   -1.39922
 69    C    4.08243    5.21781   -2.70732
 70    C    5.34316    3.30509   -1.70701
 71    H    5.36069    5.27536   -1.09143
 72    C    5.11020    5.41339   -3.85747
 73    H    3.66929    6.07468   -2.51697
 74    H    3.38482    4.61959   -3.01510
 75    C    5.75779    4.03509   -4.14096
 76    H    4.66354    5.74193   -4.65326
 77    H    5.78875    6.05533   -3.59626
 78    C    6.40351    3.59895   -2.71947
 79    H    6.44382    4.10772   -4.82336
 80    H    5.09199    3.38992   -4.43052
 81    H    6.95572    2.81229   -2.84501
 82    H    6.97114    4.31314   -2.39345
 83    H    5.73476    2.93101   -0.90109
 84    H    4.69806    2.67321   -2.06137
 85    C    8.43376    7.22633    1.27772
 86    C    8.75735    8.28980    0.28956
 87    C    8.35307    5.81798    0.56900
 88    H    8.85999    7.27198    2.15856
 89    C    9.69198    5.73389   -0.12554
 90    H    8.24574    5.10410    1.21495
 91    H    7.62278    5.78581   -0.06682
 92    C    9.96941    6.72193   -1.21293
 93    H   10.38502    5.82694    0.54673
 94    H    9.77560    4.84353   -0.50420
 95    C   10.00162    8.16508   -0.53458
 96    H    9.27489    6.68456   -1.88925
 97    H   10.82171    6.53031   -1.63411
 98    H   10.78731    8.25471    0.02835
 99    H   10.02631    8.85607   -1.21293
100    H    8.80872    9.13067    0.77149
101    H    8.00761    8.35930   -0.32196
102    C    6.50278    1.84108    7.01432
103    C    7.28044    0.78458    6.26712
104    C    5.01755    1.78217    6.64983
105    H    6.57149    1.62563    7.96806
106    C    4.62585    0.27870    6.86447
107    H    4.87778    2.04901    5.72850
108    H    4.49708    2.36180    7.22896
109    C    5.32148   -0.69994    6.03831
110    H    4.78156    0.05322    7.79391
111    H    3.67418    0.18804    6.70046
112    C    6.86575   -0.64443    6.40482
113    H    5.19434   -0.49612    5.09875
114    H    4.97170   -1.58883    6.20840
115    H    7.00953   -0.95193    7.31401
116    H    7.37939   -1.20492    5.80342
117    H    7.24906    1.00744    5.32351
118    H    8.20707    0.84878    6.54251
119    C    0.20628    5.07898    2.57975
120    C   -1.17788    5.60632    2.82071
121    C    0.12299    3.68230    1.96215
122    H    0.70535    5.68323    1.99050
123    C   -2.09672    5.44393    1.59766
124    H   -1.12354    6.54642    3.05358
125    H   -1.56781    5.13549    3.57398
126    C   -2.13396    4.00151    1.13800
127    H   -2.99320    5.73375    1.82850
128    H   -1.77409    6.00689    0.87679
129    C   -0.77977    3.40755    0.79984
130    H   -2.70051    3.94240    0.35234
131    H   -2.54195    3.46517    1.83458
132    H   -0.85827    2.45198    0.65607
133    H   -0.42430    3.81421   -0.00607
134    H    1.02042    3.43820    1.69081
135    H   -0.13232    3.07325    2.67289
136    C    1.22368    8.95953    2.26183
137    C    1.12729   10.21342    3.03333
138    C    0.58490    8.92423    0.89906
139    H    0.84462    8.23475    2.80046
140    C   -0.33067   10.76335    3.01510
141    H    1.72744   10.87617    2.65264
142    H    1.40251   10.05251    3.94859
143    C   -0.94306   10.81773    1.64018
144    H   -0.88199   10.20064    3.58208
145    H   -0.33207   11.65642    3.39579
146    C   -0.86444    9.45049    0.98209
147    H   -0.46965   11.47057    1.09953
148    H   -1.87007   11.09632    1.70701
149    H   -1.23397    9.50606    0.08707
150    H   -1.40292    8.82297    1.48832
151    H    0.58426    8.01529    0.56293
152    H    1.09749    9.47365    0.28551
153    C    9.36023    8.74574    5.21214
154    C   10.86188    8.70547    5.36199
155    C    8.95878   10.12481    5.70825
156    H    9.21073    8.77731    4.24423
157    C   11.60848   10.07555    4.97725
158    H   11.21015    7.99337    4.80108
159    H   11.07472    8.48276    6.28130
160    C   11.02957   11.31196    5.49158
161    H   12.52433   10.01664    5.29314
162    H   11.64061   10.13767    4.00934
163    C    9.64347   11.22271    4.97928
164    H   11.48770   12.09264    5.14127
165    H   11.04890   11.33807    6.46152
166    H    9.64988   11.03765    4.02756
167    H    9.17822   12.06083    5.12507
168    H    8.00026   10.23061    5.60903
169    H    9.16848   10.19519    6.65186
170    C    1.34521    4.56248    7.90731
171    C    1.40899    3.18816    7.18441
172    C    0.54823    4.35183    9.30855
173    H    0.86252    5.20662    7.34641
174    C   -0.07413    2.78935    7.12974
175    H    1.78534    3.27425    6.29547
176    H    1.92910    2.54705    7.69267
177    C   -0.80128    2.46805    8.41759
178    H   -0.55555    3.50944    6.69438
179    H   -0.14563    2.01082    6.55264
180    C   -0.86288    3.76310    9.11619
181    H   -1.69120    2.12632    8.23940
182    H   -0.31186    1.81328    8.94002
183    H   -1.28564    3.64254    9.98083
184    H   -1.40450    4.38118    8.59983
185    H    1.06264    3.75719    9.87755
186    H    0.47489    5.20576    9.76213
187    C   -0.54610    8.85187    7.55700
188    C   -1.42383    7.61911    7.56712
189    C    0.13609    9.11399    8.90357
190    H   -1.14205    9.61310    7.39500
191    C   -0.81332    9.13457   10.11650
192    H    0.59493    9.96753    8.85497
193    H    0.80788    8.42822    9.04734
194    C   -1.61822    7.79848   10.15294
195    H   -1.42237    9.88711   10.04562
196    H   -0.30118    9.23490   10.93456
197    C   -2.33420    7.77525    8.81447
198    H   -1.02569    7.03632   10.24407
199    H   -2.25370    7.79342   10.88596
200    H   -2.83653    8.60120    8.72538
201    H   -2.97165    7.04481    8.82257
202    H   -0.88524    6.81500    7.63597
203    H   -1.95664    7.57099    6.75918
204    C    5.66496   11.91514    3.03738
205    C    4.48325   12.57713    3.69345
206    C    6.75652   13.09456    3.09408
207    H    5.50202   11.51720    2.15654
208    C    4.01247   13.67426    2.75186
209    H    4.74047   12.95485    4.54999
210    H    3.77295   11.93342    3.84127
211    C    4.95307   14.81578    2.67492
212    H    3.89878   13.30013    1.86293
213    H    3.14769   13.99831    3.04953
214    C    6.28899   14.17196    2.16059
215    H    5.07738   15.22261    3.54563
216    H    4.63300   15.48946    2.05529
217    H    6.14907   13.79575    1.27772
218    H    6.97282   14.85592    2.09174
219    H    6.83302   13.43874    3.99719
220    H    7.62357   12.76089    2.81666
221    C    7.95025    7.70554    9.46245
222    C    9.08324    7.19276   10.30481
223    C    7.56261    9.04330   10.05575
224    H    8.19986    7.78177    8.51883
225    C    8.71371    9.99070    9.74796
226    H    7.43198    8.96562   11.01353
227    H    6.73901    9.36744    9.65481
228    C   10.01359    9.54163   10.38176
229    H    8.83261   10.04465    8.78612
230    H    8.49169   10.87665   10.06992
231    C   10.17136    8.09472    9.87755
232    H    9.95824    9.57114   11.34967
233    H   10.75522   10.09727   10.09017
234    H   10.20460    8.10323    8.90762
235    H   11.01530    7.73984   10.19749
236    H    8.89533    7.28281   11.25247
237    H    9.28629    6.26536   10.10435
238    C    3.58120    8.97738   12.45325
239    C    3.87228    7.63942   12.91696
240    C    4.76190    9.97412   12.52412
241    H    2.77621    9.34003   12.88051
242    C    5.22516   10.02524   13.96587
243    H    5.48641    9.67955   11.95107
244    H    4.47681   10.85355   12.23254
245    C    4.31547    9.13888   14.84873
246    H    5.19805   10.94040   14.28378
247    H    6.14155    9.71264   14.02459
248    C    4.30411    7.70335   14.37287
249    H    4.62974    9.17209   15.76602
250    H    3.41121    9.49129   14.83051
251    H    3.69312    7.18421   14.91758
252    H    5.19018    7.32063   14.46602
253    H    4.58019    7.25029   12.37833
254    H    3.08262    7.08128   12.82989
255    C    6.12615   12.74745    7.11152
256    C    5.69265   14.15817    6.96775
257    C    6.88685   12.44111    8.39531
258    H    6.60533   12.43112    6.31775
259    C    8.18621   13.33378    8.61401
260    H    7.14883   11.50780    8.38721
261    H    6.29036   12.57167    9.15061
262    C    7.69055   14.76319    8.40949
263    H    8.54378   13.21441    9.50699
264    H    8.87278   13.10822    7.96603
265    C    7.19952   14.81323    6.96572
266    H    8.41121   15.39975    8.54921
267    H    6.97027   14.96791    9.02506
268    H    7.78915   14.30147    6.38862
269    H    7.16999   15.72812    6.64578
270    H    5.15832   14.46117    7.72102
271    H    5.21541   14.31654    6.13753
272end
273
274xtb
275    chrg 0
276    uhf  0
277    gfn  1
278end
279
280task
281    energy xtb
282end

Then run it:

$ qbics aulig.inp -n 4 > aulig.out

Here, -n 4 means Qbics will use 4 CPU cores for parallization. xTB is controlled by the xtb block:

  • chrg and uhf keywords define the charge and number of unpaired electrons of the system, respectively.

  • gfn keyword defines which version of xTB will be used. Currently, Qbics supports GFN1-xTB (gfn 1) and GFN2-xTB (gfn 2). You can choose one of them according to your needs. In this example, we use GFN1-xTB (gfn 1). According to our experience, for systems NOT containing too many metallic atoms, GFN1-xTB is is much better. For other systems, GFN2-xTB is better.

You can also use implicit solvent model in xTB calculations with gbsa:

1xtb
2    chrg 0
3    uhf  0
4    gfn  1
5    gbsa h2o
6end

So the solvent h2o will be used in the xTB calculation. The list of all supported solvents can be found in xtb. Without giving gbsa, the xTB calculation will be done in gas phase.

In aulig.out, you will find the energy:

aulig.out
1xTB Iteration ... done (3.087 seconds)
2Total xTB energy: -382.97973634 Hartree
3
4Final total energy:        -382.97973634 Hartree

In aulig.inp, you can change energy to opt to do geometry optimization, or md to do molecular dynamics simulation. For more information, please refer to Geometry Optimization and Standard Molecular Dynamics Simulations, respectively.

Hint

Qbics only supports a part of the xTB functions. Some functions like GFN0-xTB are not supported. If you want to use these functions, please use the original xTB program: https://xtb-docs.readthedocs.io/en/latest/.

Example: AM1 and PM3 for An Organic Anion

We will use NDDO to calculate the energy of an organi anion, C11H17SO3-:

../_images/a15.jpg

We will first use AM1. The input file is:

c11h17so3-1.inp
 1mol
 2    C     -0.05133195      0.13820273     -0.07408260
 3    H      1.06386427      0.23393150     -0.04053791
 4    H     -0.48221807      1.16269423     -0.21129857
 5    C     -0.55764462     -0.46814486      1.23108862
 6    H     -0.25721997      0.18955243      2.08945318
 7    C     -0.45901605     -0.75614552     -1.24106425
 8    H     -0.08318986     -0.31245213     -2.20112418
 9    C      0.13909675     -2.14772780     -1.05064293
10    H      1.25634763     -2.07769530     -1.02321562
11    H     -0.14484400     -2.80323400     -1.91285383
12    C      0.04667328     -1.85701716      1.40913664
13    H     -0.28851614     -2.29736205      2.38206320
14    H      1.16439595     -1.78130414      1.43736333
15    C     -0.37460514     -2.75694197      0.25288279
16    H      0.05838753     -3.78596700      0.40210267
17    C     -1.90186350     -2.87990458      0.16288292
18    H     -2.14499703     -3.44910342     -0.78452731
19    C     -2.50285637     -3.65508897      1.30500807
20    C     -2.07739083     -0.58718463      1.18573116
21    H     -2.53453817      0.42961535      1.07690940
22    H     -2.44934230     -1.03769263      2.14165477
23    C     -1.98072027     -0.85710196     -1.28599969
24    H     -2.42386255      0.16167103     -1.42776124
25    H     -2.29241214     -1.49373089     -2.15289033
26    C     -2.49210287     -1.47123081      0.01543189
27    H     -3.61168946     -1.54021627     -0.01947598
28    S     -2.36143038     -5.42667342      1.13627320
29    O     -2.91083500     -5.72787974     -0.13380691
30    O     -3.12407542     -5.92344897      2.22190957
31    O     -0.97593034     -5.70753864      1.23827617
32    H     -3.59090253     -3.41118657      1.38165847
33    H     -2.04104042     -3.35568384      2.27489529
34end
35
36nddo
37    charge  -1
38    spin2p1  1
39end
40
41task
42    energy am1
43end

The usage of NDDO is similar to DFT. The mol section defines the molecule, and the nddo section defines the charge (charge) and spin multiplicity (spin2p1) of the system.

To use PM3, you can change the method to PM3 by replacing am1 with pm3 in the task section:

c11h17so3-2.inp
1task
2    energy pm3
3end

Of course, you can change energy to opt to do geometry optimization, or md to do molecular dynamics simulation. For more information, please refer to Geometry Optimization and Standard Molecular Dynamics Simulations, respectively.
